GIC MJ93BK Temperature Monitoring
The GIC MJ93BK Temperature Monitoring offers 220 - 440 VAC supply voltage, - 15 C to +60 C operating temperature, Base / DIN rail mounting, IP 20 for Terminals, IP 40 for Enclosure degree of protection. Manufactured by GIC under the GIC Temperature Monitoring category, this model belongs to the GIC MJ Series.
| Brand | GIC |
| Product Type | Temperature Monitoring |
| Model Number | MJ93BK |
GIC MJ93BK Temperature Monitoring – Technical Specifications
| Specification | Value |
|---|---|
| Supply Voltage | 220 - 440 VAC |
| Supply Variation | -20% to + 10% |
| Supply Frequency | 50/60 Hz |
| Power Consumption(Max) | 8 VA |
| Trip Level | 2.7 kΩ, (± 5%) |
| Reset Level | 1.71kΩ (± 5%) |
| Sensor Short | <20Ω , (±4Ω ) |
| Hysterisis | 40Ω (±4Ω ) |
| Sensor Open | > 20kΩ (± 5%) |
| Max Cold Res( ) of Sensor Chain | < 1.5 kΩ |
| Reset Mode | Auto, Manual, Remote |
| Repeat Accuracy | 1% |
| ON Delay | < 350 ms |
| OFF Delay | 100 ms |
| Reset Time | 150 ms |
| Coil Output | 2 C/O |
| Contact Rating | 5A (Resistive) @ 250 VAC / 28 VDC |
| Electrical Life | 1 x 10^5 |
| Mechanical Life | 1 x 10^6 |
| Utilization Category AC - 15 | Rated Voltage (Ue): 120/240 V, Rated Current (Ie): 3.0/1.5 A |
| Utilization Category DC - 13 | Rated Voltage (Ue): 24/125/250 V, Rated Current (Ie): 2.0/0.22/0.1 A |
| Operating Temperature | - 15 C to +60 C |
| Storage Temperature | - 25 C to +80 C |
| Relative Humidity | 95% (Rh) |
| Degree of Protection | IP 20 for Terminals, IP 40 for Enclosure |
| Dimension (W x H x D) (in mm) | 22.5 X 83 X 100.5 |
| Enclosure | Flame Retardant UL94-V0 |
| Weight (unpacked) | 120 g |
| Mounting | Base / DIN rail |
