Home GIC Timers DT Series BR32B1 GIC BR32B1 Timer The GIC BR32B1 Timers offers 95% to 105% frequency, -5°C to 45°C operating Temperature, IP20 degree of protection , 96 X 96 X 100 Dimensions (W X H X D). Manufactured by GIC under the GIC Timers category, this model belongs to the GIC DT Series .
Brand GIC Product Type Timers Model Number BR32B1
GIC BR32B1 Timer – Technical Specifications Specification Value Timing range 0.15s to 120h Timing Ranges(SR) & (MR) 0.6 - 12 MIN Voltage 110V AC 50 Hz Delay Standard ON delay Mounting Base Mounting Contact 1 Inst + 2 Del C/O Supply Variation - 20% to +10% Frequency 95% to 105% Power consumption 10 VAC Output Contact 1 Instant + 1 Delayed / 1 Instant + 2 Delayed (Optional) Contact rating 6A (resistive) @ 250 VAC Switching Frequency 3000 operations/hr. (Max.) Repeat Accuracy ± 0.5% of Full Scale Range @ Constant Frequency Operating Temperature -5°C to 45°C Enclosure Conforms to IP30 - IS 13947. Degree of Protection IP20 Terminal Connection 1– 2.5 mm² solid/stranded. Dimensions (W X H X D) in mm 96 X 96 X 100 Weight (Unpacked) 530 g
