AS1SCDS - GIC Digital Time Switches
The GIC AS1SCDS Digital Time Switches offers 240 VAC Supply voltage, 1 C/O output relay, DIN rail mounting , IP20 for Terminals, IP40 for Enclosure degree of Protection. Manufactured by GIC under the GIC Digital Time Switches category, this model belongs to the GIC AT Series.
| Brand | GIC |
| Product Type | Digital Time Switches |
| Model Number | AS1SCDS |
AS1SCDS GIC Digital Time Switches Technical Specifications
| Specification | Value |
|---|---|
| Supply Voltage | 240 VAC |
| Supply Variation | -20 % to +10% |
| Frequency | 50/60 Hz |
| Power Consumption (Max.) | 6 VA |
| Minimum Switching Time | 1 min |
| Trigger Modes | Sunrise/Sunset or Twilight Rise/Set |
| Offset | 00 to 99 minutes (Programmable) |
| OFF Hours | Programmable |
| Number of Operating Modes | 5 |
| Display | LCD with backlight |
| DST | User Defined |
| Clock Accuracy | ± 2 s/day max. over the Operating Temperature range |
| Power Reserve from Factory | 6 Years |
| Outpu Contact Rating | 16A (NO) & 5A (NC) @ 240 VAC / 24 VDC (Resistive) |
| Outpu Electrical Life | 5x10^4 |
| Outpu Mechanical Life | 5x10^4 |
| Utilization Category AC - 15 | 16 A (NO & NC) at 250 VAC,Cos =1 |
| Utilization Category DC - 13 | 10 A (NO & NC) at 250 VAC,Cos =0.6 |
| Operating Temperature | -15°C to + 55°C |
| Storage Temperature | -20°C to + 70°C |
| Humidity (Non Condensing) | 95% (Rh) |
| LED Indication | Indication on LCD |
| Enclosure | Flame Retardant UL 94-V0 |
| Dimension (W x H x D) (in mm) | 36 X 90 X 65 |
| Weight (unpacked) Approx. | 110 g |
| Mounting | DIN rail |
| Degree of Protection | IP20 for Terminals, IP40 for Enclosure |
