Home GIC Gateway SC Series 2SC3D11EC3 GIC 2SC3D11EC3 Gateway The GIC 2SC3D11EC3 Gateway offers 24 V DC supply voltage, -10°C to +55°C operating temperature, 22.5 X 83 X 100.5 dimension (W x H x D) , Din Rail Mounting mounting. Manufactured by GIC under the GIC Gateway category, this model belongs to the GIC SC Series .
Brand GIC Product Type Gateway Model Number 2SC3D11EC3
GIC 2SC3D11EC3 Gateway – Technical Specifications Specification Value Supply Voltage 24 V DC Supply Variation -15% to +15% Power Consumption (Max.) 4 VA Input Signal 0-10V DC, 2-10V DC, 0-10mA DC, 2-10mA DC Input Impedance Voltage I/P - 100K Ohm approx., Current I/P - 200 Ohm approx. Output Signal 0-10VDC, 2-10VDC (min. 1 kOhm load) 0-20mA DC,4-20mA DC (max. 500 Ohm load) Accuracy 1% of full Scale Offset ± 5% of full scale Adjustable Gain ± 10% of full scale Adjustable Linearity <0.02% of full scale Input supply reverse polarity Yes Input signal reverse polarity Yes Output short circuit current <25mA (Output Voltage mode) Output open circuit voltage (12-14)VDC (Output Current mode) LED Indications GREEN LED: Power ON Operating Temperature -10°C to +55°C Storage Temperature -15°C to +60°C Humidity (Non Condensing) 95% (Rh) Enclosure Flame Retardant UL94-V0 Dimension (W x H x D) (in mm) 22.5 X 83 X 100.5 Weight (unpacked) 130 g Mounting Din Rail Mounting Degree of Protection IP 20 for Terminals, IP 40 for Enclosure
