GIC 2ASDT0 Timer
The GIC 2ASDT0 Timers offers 50/60 Hz frequency, -15°C to +60°C operating Temperature, IP 20 for Terminals, IP 40 for Enclosure degree of protection , 22.5 X 75 X 100.5 Dimensions (W X H X D). Manufactured by GIC under the GIC Timers category, this model belongs to the GIC DT Series.
| Brand | GIC |
| Product Type | Timers |
| Model Number | 2ASDT0 |
GIC 2ASDT0 Timer – Technical Specifications
| Specification | Value |
|---|---|
| Timer Description | Star Delta Timer |
| Timing range | 3s to 120s |
| Mounting | Base / DIN Rail |
| Supply Voltage (Un) | 24 - 240 VAC/DC |
| Supply Variation | - 20% to +10% |
| Frequency | 50/60 Hz |
| Power consumption | 4 VA |
| Relay Output | Star - 1 'NO', Delta - 1 'NO' |
| Contact rating | 5A @ 240 VAC / 28 VDC (Resistive) |
| Electrical Life | 1×10^5 |
| Mechanical Life | 1×10^7 |
| Repeat Accuracy | ± 1% |
| Reset Time | 200 ms (Max.) |
| Setting Accuracy | ± 5% of Full scale |
| Operating Temperature | -15°C to +60°C |
| Storage Temperature | -20°C to +80°C |
| Humidity | 95% (Rh) |
| Utilization Category AC - 15 | Rated Voltage (Ue): 230/125 V, Rated Current (Ie): 1.3/2.5 A |
| Utilization Category DC - 13 | Rated Voltage (Ue): 250/120/24 V, Rated Current (Ie): 0.1/0.22/2 A |
| LED Indication | Red LED 1 ON, Red LED 2 ON |
| Enclosure | Flame Retardant UL94-V0 |
| Degree of Protection | IP 20 for Terminals, IP 40 for Enclosure |
| Dimensions (W X H X D) in mm | 22.5 X 75 X 100.5 |
| Weight (Unpacked) | 130 g |
The GIC 2ASDT0 Timer is designed for precision motor startup control with a configurable timing range of 3s to 120s. It supports a wide supply voltage from 24–240 VAC/DC, ensuring flexibility across varied power conditions. With two NO relay outputs rated at 5A @ 240 VAC / 28 VDC, it provides dependable star and delta transition logic while minimizing inrush currents. Its repeat accuracy of ±1% and reset time under 200 ms make it suitable for consistent high-duty cycle operations in demanding industries.
Durability is a key advantage of the 2ASDT0. It is housed in a UL94-V0 flame-retardant enclosure with IP20/IP40 protection, offering both mechanical strength and electrical safety. The device ensures long service life with an electrical life of 1×10⁵ cycles and mechanical life of 1×10⁷ operations. Compact dimensions of 22.5 × 75 × 100.5 mm and light weight (130 g) make it panel-friendly, while LED indicators provide clear visual status for star and delta modes, simplifying operation and troubleshooting. Operating between -15°C to +60°C and handling up to 95% humidity, the unit performs reliably in tough plant conditions.
In real-world use, the GIC 2ASDT0 Timer is trusted in three-phase motor starters, automation panels, utilities, and heavy machinery setups where accurate transition from star to delta is essential. OEMs and panel builders value its compact design and safety certifications, while maintenance engineers appreciate its ease of installation and stable performance over time. This timer not only safeguards motors but also improves operational efficiency, making it a preferred choice for industries focused on long-term reliability and reduced downtime. For more details or callback requests, visit the official GIC product page.
