Home GIC Timers DT Series 23LDT0 GIC 23LDT0 Timer The GIC 23LDT0 Timers offers 50/60 Hz frequency, -15°C to +60°C operating Temperature, IP 20 for Terminals, IP 40 for Enclosure degree of protection , 22.5 X 75 X 100.5 Dimensions (W X H X D). Manufactured by GIC under the GIC Timers category, this model belongs to the GIC DT Series .
Brand GIC Product Type Timers Model Number 23LDT0
GIC 23LDT0 Timer – Technical Specifications Specification Value Timer Description Motor Restart Control Timer Timing range Memory Time (Tm): 0.2 to 6s, Delay Time (Td): 0.2 to 60s Mounting Base / DIN Rail Supply Voltage (Un) 110 VAC Supply Variation - 20% to +10% Frequency 50/60 Hz Power consumption 2 VA Relay Output 1 C/O Contact rating 5A @ 240 VAC / 28 VDC (Resistive) Electrical Life 1×10^5 Mechanical Life 1×10^7 Repeat Accuracy ± 1% Reset Time 200 ms (Max.) Setting Accuracy ± 5% of Full scale Operating Temperature -15°C to +60°C Storage Temperature -20°C to +70°C Humidity 95% (Rh) Utilization Category AC - 15 Rated Voltage (Ue): 230/125 V, Rated Current (Ie): 1.3/2.5 A Utilization Category DC - 13 Rated Voltage (Ue): 250/120/24 V, Rated Current (Ie): 0.1/0.22/2 A Enclosure Flame Retardant UL94-V0 Degree of Protection IP 20 for Terminals, IP 40 for Enclosure Dimensions (W X H X D) in mm 22.5 X 75 X 100.5 Weight (Unpacked) 130 g
