GIC 1CQDT9 Timer
The GIC 1CQDT9 Timers offers 50/60 Hz frequency, -10°C to +60°C operating Temperature, IP 20 for Terminals, IP 30 for Enclosure, IP 40 for Front side degree of protection , 18 X 60 X 85 Dimensions (W X H X D). Manufactured by GIC under the GIC Timers category, this model belongs to the GIC DT Series.
| Brand | GIC |
| Product Type | Timers |
| Model Number | 1CQDT9 |
GIC 1CQDT9 Timer – Technical Specifications
| Specification | Value |
|---|---|
| Timer Description | Multi Function Timer |
| Timing range | 0.1s to 100h |
| Mounting | DIN Rail |
| Supply Voltage (Un) | 12 - 240 VAC/DC |
| Supply Variation | -15% to +10% |
| Frequency | 50/60 Hz |
| Power consumption | 5 VA |
| Relay Output | 1 C/O |
| Contact rating | 16A @ 240 VAC / 16A @24 VDC (Resistive) |
| Electrical Life | 5×10^6 |
| Mechanical Life | 1×10^5 |
| Repeat Accuracy | ± 1% |
| Reset Time | 200 ms (Max) |
| Setting Accuracy | ± 5% of Full scale |
| Operating Temperature | -10°C to +60°C |
| Storage Temperature | -15°C to +70°C |
| Utilization Category AC - 15 | Rated Voltage (Ue): 120/240 V, Rated Current (Ie): 3.0/1.5 A |
| Utilization Category DC - 13 | Rated Voltage (Ue): 24/125/250 V, Rated Current (Ie): 2.0/0.22/0.1 A |
| LED Indication | Green LED, Power ON Yellow LED, Relay ON |
| Enclosure | Flame Retardant UL94-V0 |
| Degree of Protection | IP 20 for Terminals, IP 30 for Enclosure, IP 40 for Front side |
| Dimensions (W X H X D) in mm | 18 X 60 X 85 |
| Weight (Unpacked) | 72 g |
