GIC 151J42B Temperature Controller
The GIC 151J42B Temperature Controller offers Dual row 7 segment display with LED indications, 4-digit process value, 4 digit set value display, 96 x 96 x 69.1 dimensions (W x H x D), 110 - 240 VAC/DC supply voltage, 0 C to +50 C operating temperature. Manufactured by GIC under the GIC Temperature Controller category, this model belongs to the GIC TCS Series.
| Brand | GIC |
| Product Type | Temperature Controller |
| Model Number | 151J42B |
GIC 151J42B Temperature Controller – Technical Specifications
| Specification | Value |
|---|---|
| Display | Dual row 7 segment display with LED indications, 4-digit process value, 4 digit set value |
| Output 1 | Relay: SPST 5A @ 240 VAC / 24 VDC |
| Output 2 | Relay: SPST 5A @ 240 VAC / 24 VDC |
| Output 3 | Relay: SPST 5A @ 240 VAC / 24 VDC |
| Mounting | Flush |
| Dimensions (W x H x D) (in mm) | 96 x 96 x 69.1 |
| Operating temperature | 0 C to +50 C |
| Storage Temperature | -20 C to +60 C |
| Relative humidity | 80% (Rh) |
| Ramp Soak Feature | No |
| Enclosure | Flame Retardant UL94V0 |
| Degree of Protection | IP 20 Terminal & Enclosure, IP 40 (For Front Panel only) |
| Supply Voltage | 110 - 240 VAC/DC |
| Supply Variation | -20% to +20% |
| Frequency | 50/60 Hz |
| Alarm Types | Absolute (High/Low/Band), Deviation (High/Low/Band), Sensor Break, Loop Break, |
| Controlling action | ON/OFF (Symmetric / Asymmetric), PID (Single Acting) |
| Tune method | Auto Tuning / Manual Tuning |
| Analog Input | 0-5 V, 1-5 V, 0-10 V / 4-20 mA |
| Measurement Ranges J type | 0 to 700°C/32 to 1292°F |
| Measurement Ranges K type | 0 to 1300°C/32 to 2372°F |
| Measurement Ranges PT-100 | - 200 to 700°C/-328 to 1292°F |
| Measurement Ranges E type | 0 to 600°C/32 to 1112°F |
| Measurement Ranges B type | 250 to 1820°C/482 to 3308°F |
