SEU-3/8 - 6755 - Festo Stop Valves
SEU-3/8 6755 Festo Stop Valves
| Brand | Festo |
| Product Type | Stop Valves |
| Product | SEU-3/8 |
SEU-3/8 6755 Festo Stop Valves Technical Specifications
| Specification | Value |
|---|
| Valve function | Quick exhaust |
| Pneumatic connection, port 1 | G3/8 |
| Pneumatic connection, port 2 | G3/8 |
| Type of mounting | Screw-in |
| Operating pressure | 0.2; 10 |
| Ambient temperature | -20; 75 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Mounting position | optional |
| Symbol | 991460 |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Media temperature | -20; 75 |
| Product weight | 160 |
| Material seals | NBR |
