HE-3-1/8-1/8 - 153296 - Festo Stop Valves
HE-3-1/8-1/8 153296 Festo Stop Valves
| Brand | Festo |
| Product Type | Stop Valves |
| Product | HE-3-1/8-1/8 |
HE-3-1/8-1/8 153296 Festo Stop Valves Technical Specifications
| Specification | Value |
|---|---|
| Valve function | 3/2 double solenoid |
| Pneumatic connection, port 1 | R1/8 |
| Pneumatic connection, port 2 | R1/8 |
| Type of actuation | Manual |
| Type of mounting | Either:; Direct mounting via through-hole; Direct mounting via thread |
| Operating pressure | -0.95; 10 |
| Ambient temperature | 0; 60 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Mounting position | optional |
| Symbol | 997329 |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Cleanroom class | Class 4 according to ISO 14644-1 |
| Media temperature | 0; 60 |
| Product weight | 35 |
| Note on materials | RoHS-compliant |
| Material seals | NBR |
