Festo DZH-16-PPV-A-S20 Pneumatic Cylinder
The Festo DZH-16-PPV-A-S20 Pneumatic Cylinder offers M6 rod thread, TPE-U(PU) connection, 16 mm; Equivalent diameter diameter, andPiston; Piston rod; Profile barrel. Manufactured by Festo under the Festo Pneumatic Cylinder category, this model belongs to the DZH Series.
| Brand | Festo |
| Product Type | Flat Type |
| Product | DZH-16-PPV-A-S20 |
Festo DZH-16-PPV-A-S20 Pneumatic Cylinder โ Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 1; 200 |
| Piston diameter | 16 mm; Equivalent diameter |
| Piston rod thread | M6 |
| Torsional backlash at piston rod +/- | 3.1 |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Design | Piston; Piston rod; Profile barrel |
| Position detection | Via proximity switch |
| Symbol | 991236 |
| Variants | Through, hollow piston rod |
| Protection against torque/guide | Oval piston |
| Operating pressure | 1; 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -20; 80 |
| Cushioning length | 14 |
| Basic weight for 0 mm stroke | 178 |
| Type of mounting | Either:; Via female thread; With accessories |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Material cover | Aluminium |
| Material seals | TPE-U(PU) |
| Material housing | Aluminium |
| Material piston seal | TPE-U(PU) |
| Material piston rod | High-alloy steel |
