Festo DZF-18-A-P-A-S6 Pneumatic Cylinder
The Festo DZF-18-A-P-A-S6 Pneumatic Cylinder offers 1.2 piston rod thread, M5 connection, 18 mm; Equivalent diameter diameter, andPiston; Piston rod. Manufactured by Festo under the Festo Pneumatic Cylinder category, this model belongs to the DZF Series.
| Brand | Festo |
| Product Type | Flat Cylinder |
| Product | DZF-18-A-P-A-S6 |
Festo DZF-18-A-P-A-S6 Pneumatic Cylinder โ Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 1; 200 |
| Piston diameter | 18 mm; Equivalent diameter |
| Piston rod thread | M8 |
| Torsional backlash at piston rod +/- | 1.2 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Design | Piston; Piston rod |
| Position detection | Via proximity switch |
| Symbol | 991217 |
| Variants | Heat-resistant seals max. 120ยฐC |
| Protection against torque/guide | Oval piston |
| Operating pressure | 1; 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | 0; 120 |
| Impact energy in end positions | 0.05 |
| Moving mass for 0 mm stroke | 24 |
| Basic weight for 0 mm stroke | 107 |
| Type of mounting | Either:; Via female thread; With accessories |
| Pneumatic connection | M5 |
| Material cover | Wrought aluminium alloy |
| Material seals | FPM |
| Material housing | Anodised wrought aluminium alloy |
| Material piston seal | HNBR |
| Material piston rod | High-alloy stainless steel |
