Festo DZF-12-100-A-P-A Pneumatic Cylinder
The Festo DZF-12-100-A-P-A Pneumatic Cylinder offers 2.5 piston rod thread, M5 connection, 12 mm; Equivalent diameter diameter, andPiston; Piston rod. Manufactured by Festo under the Festo Pneumatic Cylinder category, this model belongs to the DZF Series.
| Brand | Festo |
| Product Type | Flat Cylinder |
| Product | DZF-12-100-A-P-A |
Festo DZF-12-100-A-P-A Pneumatic Cylinder – Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 100 |
| Piston diameter | 12 mm; Equivalent diameter |
| Piston rod thread | M6 |
| Torsional backlash at piston rod +/- | 2.5 |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Design | Piston; Piston rod |
| Position detection | Via proximity switch |
| Symbol | 991217 |
| Variants | Piston rod at one end |
| Protection against torque/guide | Oval piston |
| Operating pressure | 1.6; 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -20; 80 |
| Impact energy in end positions | 0.09 |
| Moving mass for 0 mm stroke | 12 |
| Basic weight for 0 mm stroke | 96 |
| Type of mounting | Either:; Via female thread; With accessories |
| Pneumatic connection | M5 |
| Material cover | Wrought aluminium alloy |
| Material seals | NBR; TPE-U(PU) |
| Material housing | Anodised wrought aluminium alloy |
| Material piston seal | NBR |
| Material piston rod | High-alloy stainless steel |
