Festo CRHD-80- -PPV-A-MQ-S6 Pneumatic Cylinder
The Festo CRHD-80- -PPV-A-MQ-S6 Pneumatic Cylinder offers Double-acting operation, G3/8 connection, 80 mm diameter, andPiston; Piston rod. Manufactured by Festo under the Festo Pneumatic Cylinder category, this model belongs to the CRHD Series.
| Brand | Festo |
| Product Type | Round Cylinder |
| Product | CRHD-80- -PPV-A-MQ-S6 |
Festo CRHD-80- -PPV-A-MQ-S6 Pneumatic Cylinder – Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 10; 500 |
| Piston diameter | 80 mm |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | optional |
| Design | Piston; Piston rod |
| Position detection | Via proximity switch |
| Symbol | 991235 |
| Variants | Heat-resistant seals max. 120°C |
| Operating pressure | 1; 10 |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 3 - high corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Suitable for use with food | See supplementary material information |
| Ambient temperature | -20; 120 |
| Cushioning length | 31 |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 2721 |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 3016 |
| Moving mass for 0 mm stroke | 717 |
| Additional moving mass per 10 mm stroke | 38 |
| Basic weight for 0 mm stroke | 5072 |
| Additional weight per 10 mm stroke | 38 |
| Pneumatic connection | G3/8 |
| Material cover | High-alloy stainless steel |
| Material seals | FPM |
| Material housing | High-alloy stainless steel |
| Material piston rod | High-alloy stainless steel |
Engineered for demanding environments, the Festo CRHD-80-PPV-A-MQ-S6 round cylinder is built with a high-alloy stainless steel body and features a double-acting mechanism that delivers strong and balanced thrust in both directions. With a piston diameter of 80 mm and a stroke range up to 500 mm, this cylinder achieves a maximum advance stroke force of 3016 N and a return stroke force of 2721 N at 6 bar. The pneumatic cushioning on both ends is adjustable, ensuring smooth motion with reduced mechanical stress.
The cylinder operates efficiently across a wide ambient temperature range of -20°C to 120°C, thanks to its heat-resistant FPM seals. It supports compressed air per ISO 8573-1:2010 [7:4:4] and offers optional lubricated operation for extended service life. Featuring G3/8 pneumatic connections and position sensing via proximity switches, this model integrates seamlessly into automated systems. Its corrosion resistance class CRC 3 makes it ideal for harsh, moisture-prone, or chemically sensitive environments.
Weighing just over 5 kg (basic weight for 0 mm stroke: 5072 g), with a compact and robust design, the CRHD-80-PPV-A-MQ-S6 is trusted by engineers worldwide for its reliability, long lifecycle, and consistent performance. Certified with VDMA24364-B2-L for PWIS conformity, it is also suitable for sensitive production zones like food, pharma, and automotive paint shops. For more details, refer to the official Festo product page.
The Festo Round Cylinder CRHD-80-PPV-A-MQ-S6 is commonly used in applications where precise, high-force linear motion is required under tough environmental conditions. In packaging lines, it is used to actuate pressing or sealing arms with exact repeatability. In material handling, it provides smooth linear extension for pushing, lifting, or part sorting.
Its compatibility with high ambient temperatures and corrosive surroundings makes it ideal for furnace loading systems, washing stations, and food-grade machinery. The integrated proximity sensing allows engineers to monitor stroke completion in real-time, enhancing safety and control in fully automated PLC setups.
For Indian maintenance teams and automation engineers, this model simplifies integration and service. The adjustable cushioning minimizes impact wear, and the long lifecycle reduces replacement downtime. Whether you're installing in a new system or upgrading an old actuator, the CRHD-80-PPV-A-MQ-S6 ensures lasting performance with minimal maintenance.
