AEN-S-63-10-I-P-A - 5132651 - Festo Compact Cylinder
AEN-S-63-10-I-P-A 5132651 Festo Compact Cylinder
| Brand | Festo |
| Product Type | Compact Cylinder |
| Product | AEN-S-63-10-I-P-A |
AEN-S-63-10-I-P-A 5132651 Festo Compact Cylinder Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 10 |
| Piston diameter | 63 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Design | Piston; Piston rod |
| Variants | Piston rod at one end |
| Operating pressure | 14.5; 145 |
| Mode of operation | Pushing |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | 0; 80 |
| Type of mounting | Either:; With through-hole; Via female thread; With accessories |
| Pneumatic connection | G1/8 |
| Material cover | Anodised wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
| Position detection | Via proximity switch |
| Piston-rod end | Female thread |
| Symbol | 991729 |
| Material dynamic seals | TPE-U(PU) |
| Material housing | Anodised wrought aluminium alloy |
