Festo ADN-S-63-45-I-P-A Pneumatic Cylinder
The Festo ADN-S-63-45-I-P-A Pneumatic Cylinder offers Double-acting operation, Female thread piston rod end, G1/8 connection, 63 mm diameter, andVia proximity switch. Manufactured by Festo under the Festo Pneumatic Cylinder category, this model belongs to the ADN Series.
| Brand | Festo |
| Product Type | Compact Cylinder |
| Product | ADN-S-63-45-I-P-A |
Festo ADN-S-63-45-I-P-A Pneumatic Cylinder – Technical Specifications
| Specification | Value |
|---|---|
| Stroke | 45 |
| Piston diameter | 63 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Mounting position | optional |
| Mode of operation | Double-acting |
| Piston-rod end | Female thread |
| Design | Piston; Piston rod |
| Position detection | Via proximity switch |
| Symbol | 991217 |
| Variants | Piston rod at one end |
| Operating pressure | 0.4; 10 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | 0; 80 |
| Impact energy in end positions | 1.3 |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 1750 |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 1870 |
| Type of mounting | Either:; With through-hole; Via female thread; With accessories |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Material cover | Anodised wrought aluminium alloy |
| Material dynamic seals | TPE-U(PU) |
| Material housing | Anodised wrought aluminium alloy |
| Material piston rod | High-alloy stainless steel |
