Di-soric USGT 60/8 IU-B4 Ultrasonic Sensor
The Di-soric USGT 60/8 IU-B4 Ultrasonic Sensor offers Fork design, range, output, andConnector, M12, 4-pin connection. Manufactured by Di-soric under the Di-soric Ultrasonic Sensor category, this model belongs to the US Series.
| Brand | Di-soric |
| Product Type | Ultrasonic Sensor |
| Model Number | USGT 60/8 IU-B4 |
Di-soric USGT 60/8 IU-B4 Ultrasonic Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Operating principle | Ultrasonic through-beam sensor |
| Evaluation | analog |
| Design | Fork |
| Service voltage | 12 … 30 V DC |
| No-load current (max.) | 40 mA (24 V DC) |
| Insulation voltage endurance | 500 V |
| Resolution | 0.1 mm |
| Reproducibility | ± 0.1 mm |
| Ambient temperature during operation | 0 … +60 °C |
| Protection type | IP 67 |
| Connection | Connector, M12, 4-pin |
| Connection cable | VKHM … /4 |
| Measuring range | 8 mm (typ.) |
| Protection class | III, operation on protective low voltage |
| Housing material | Aluminum (Black, Anodized) |
