di-soric OT21-PS-0.3T3: 212983 - Diffuse Reflective Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OT21-PS-0.3T3 |
di-soric Diffuse Reflective Sensors OT21-PS-0.3T3, 212983 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Retroreflective diffuse sensor |
| Evaluation | digital |
| Design | Cuboid design |
| Switching output | pnp, 100 mA, NO/NC, configurable |
| Voltage drop (max.) | 2.5 V |
| Light source | LED |
| Color | Red |
| Wavelength | 633 nm |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 20 mA |
| Insulation voltage endurance | 500 V |
| Housing dimensions | 28.1 x 8.1 x 14.4 mm |
| Housing length | 8.1 mm |
| Housing height | 28.1 mm |
| Housing width | 14.4 mm |
| Housing material | Stainless steel / Plastic |
| Protection class | III, operation on protective low voltage |
| Approvals | UL |
| Modulation | Clocked |
| Sensitivity adjustment | IO-Link |
| Switching frequency | 1000 Hz |
| Ambient temperature during operation | -25 … +60 °C |
| Protection type | IP 65 / IP 67 |
| Connection | Pigtail, 0.3 m, M8, 3-pin |
| Connection cable | TK … |
| Display | LED Green - Status, yellow - Switching output |
| Material | Plastic (Window / optics) |
| Material of cable | PVC |
| Scanning range | 0 … 180 mm (configurable) |
| Weight | 21 g |
