di-soric OT 18 FM 400 N3: 207927 - Diffuse Reflective Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OT 18 FM 400 N3 |
di-soric Diffuse Reflective Sensors OT 18 FM 400 N3, 207927 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Retroreflective diffuse sensor |
| Evaluation | digital |
| Design | Thread |
| Switching output | npn, 100 mA, NO/NC |
| Light source | LED |
| Color | Infrared |
| Wavelength | 880 nm |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 30 mA |
| Housing length | 44.5 mm |
| Housing material | Metal |
| Protection class | III, operation on protective low voltage |
| Modulation | Clocked |
| Ambient light immunity | 3 kLx Clocked light, 10 kLx Sunlight |
| Sensitivity adjustment | Potentiometer |
| Switching frequency | 1000 Hz |
| Ambient temperature during operation | -25 … +55 °C |
| Protection type | IP 67 |
| Connection | Cable, 2.0 m |
| Response time | 0.50 ms |
| Release time | 0.50 ms |
| Material | PMMA (Window) |
| Thread | M18 x 1 |
| Material of cable | PVC |
| Scanning range | 400 mm |
