di-soric OR 6-41 K 4 N2-T3: 206208 - Retro-reflective Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OR 6-41 K 4 N2-T3 |
di-soric Retro-reflective Sensors OR 6-41 K 4 N2-T3, 206208 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Retroreflective sensor |
| Evaluation | digital |
| Design | Cuboid design |
| Switching output | npn, 100 mA, NO |
| Light source | LED |
| Color | Red |
| Wavelength | 630 … 670 nm |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 25 mA |
| Housing dimensions | 38 x 27 x 15 mm |
| Housing length | 27 mm |
| Housing height | 38 mm |
| Housing width | 15 mm |
| Housing material | Plastic |
| Protection class | III, operation on protective low voltage |
| Modulation | Clocked |
| Ambient light immunity | 5 kLx |
| Sensitivity adjustment | Potentiometer |
| Switching frequency | 500 Hz |
| Ambient temperature during operation | -25 … +60 °C |
| Protection type | IP 67 |
| Connection | Connector, M8, 3-pin |
| Connection cable | TK … |
| Range | 400 … 10000 mm |
| Switching distance | 400 … 4000 mm (R55), 900 … 9000 mm (R 84), 1000 … 10000 mm (R 100x100) |
| Material | Plastic (Window) |
| Referring reflector | Reflector R55 included |
