di-soric OLK 71 N3-3: 209977 - Plastic Fiber Optic Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OLK 71 N3-3 |
di-soric Plastic Fiber Optic Sensors OLK 71 N3-3, 209977 Technical Specifications:
| Specification | Value |
|---|
| Evaluation | digital |
| Design | Cuboid design |
| Switching output | npn, 100 mA, NO/NC, programmable |
| Light source | LED |
| Color | Red |
| Wavelength | 625 nm |
| Service voltage | 12 … 24 V DC (± 10%) |
| No-load current (max.) | 40 mA |
| Insulation voltage endurance | 1000 V |
| Housing length | 69 mm |
| Housing height | 33.4 mm |
| Housing width | 10.5 mm |
| Housing material | Plastic (ABS) / Plastic (PC) |
| Protection class | III, operation on protective low voltage |
| Ambient light immunity | 10 kLx |
| Sensitivity adjustment | Teach button |
| Switching frequency | 1000 Hz / 800 Hz / 600 Hz / 400 Hz / 200 Hz |
| Ambient temperature during operation | -10 … +55 °C |
| Protection type | IP 54 |
| Connection | Cable, 2.0 m |
| Display | Digital display |
| Response time | 0.25 / 0.31 / 0.42 / 0.63 / 1.25 ms |
