di-soric OKTTI 55 M 30 FG3LK-IBS: 203675 - Contrast Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OKTTI 55 M 30 FG3LK-IBS |
di-soric Contrast Sensors OKTTI 55 M 30 FG3LK-IBS, 203675 Technical Specifications:
| Specification | Value |
|---|
| Design | Cuboid design |
| Switching output | Push-pull, 200 mA, NO/NC, switchable |
| Voltage drop (max.) | 2 V |
| Light source | LED |
| Color | White |
| Service voltage | 10 … 35 V DC |
| No-load current (max.) | 40 mA |
| Insulation voltage endurance | 500 V |
| Housing dimensions | 50 x 40 x 15 mm |
| Housing length | 40 mm |
| Housing height | 50 mm |
| Housing width | 15 mm |
| Housing material | Die-cast zinc (Black, painted) |
| Protection class | III, operation on protective low voltage |
| Modulation | Clocked |
| Ambient light immunity | 20 kLx |
| Resolution | Ø 0.7 mm |
| Switching hysteresis (max.) | 0.01 mm |
| Sensitivity adjustment | Teach button, Remote teach |
| Switching frequency | 3000 Hz |
| Ambient temperature during operation | -10 … +60 °C |
| Protection type | IP 67 |
| Connection | Connector, M12, 4-pin |
| Connection cable | VK … |
| Switching distance | 27 … 33 mm |
