di-soric OH 18-1 M 130 P4-B4: 208300 - Background Suppression Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OH 18-1 M 130 P4-B4 |
di-soric Background Suppression Sensors OH 18-1 M 130 P4-B4, 208300 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Diffuse sensor with background suppression |
| Evaluation | digital |
| Design | Thread |
| Switching output | pnp, 100 mA, antivalent |
| Voltage drop (max.) | 2 V |
| Light source | LED |
| Color | Red |
| Wavelength | 660 nm |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 25 mA |
| Insulation voltage endurance | 500 V |
| Housing length | 80 mm |
| Housing material | Brass (CuZn, nickel-plated) |
| Protection class | III, operation on protective low voltage |
| Modulation | Clocked |
| Ambient light immunity | 5 kLx Halogen light, 10 kLx Sunlight |
| Switching hysteresis (max.) | 10 % |
| Sensitivity adjustment | Potentiometer |
| Switching frequency | 1000 Hz |
| Ambient temperature during operation | -25 … +70 °C |
| Protection type | IP 67 |
| Connection | Connector, M12, 4-pin |
| Response time | 0.50 ms |
| Release time | 0.50 ms |
| Material | PMMA (Window) |
| Thread | M18 x 1 |
| Scanning range | 30 … 130 mm |
