di-soric OGWTI-30G3-T4: 213353 - Frame Light Barriers
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OGWTI-30G3-T4 |
di-soric Frame Light Barriers OGWTI-30G3-T4, 213353 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Optical |
| Evaluation | Switching, Dynamic/static switchable |
| Design | Fork |
| Switching output | Push-pull, 100 mA, NO/NC, switchable |
| Voltage drop (max.) | 2 V |
| Light source | LED |
| Color | Infrared |
| Service voltage | 18 … 30 V DC |
| No-load current (max.) | < 45 mA |
| Housing dimensions | 66 x 54 x 12 mm |
| Housing material | Die-cast zinc (Black, powder-coated) |
| Approvals | UL |
| Resolution | Ø 0.7 mm (dynamic), Ø 1.0 mm (static) |
| Sensitivity adjustment | Keypad |
| Ambient temperature during operation | -10 … +60 °C |
| Protection type | IP 67 |
| Connection | Connector, M8, 4-pin |
| Connection cable | TK … /4 |
| Display | LED Green - Status, yellow - Switching output 1, white - static/dynamic, yellow/red - Switching output 2 / Warning |
| Response time | 0.05 ms |
| Release time | 0.05 … 10000 ms |
| Material | Plastic (Window) |
| Operating modes | Static, Dynamic, Shadowing |
| Detection range | 30 x 30 mm |
| Weight | 92 g |
