di-soric OES 18 FK 10000 P3-B4: 207916 - Through-beam Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OES 18 FK 10000 P3-B4 |
di-soric Through-beam Sensors OES 18 FK 10000 P3-B4, 207916 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Through-beam sensor |
| Evaluation | digital |
| Design | Thread |
| Switching output | pnp, 100 mA, NO/NC |
| Light source | LED |
| Color | Infrared |
| Wavelength | 880 nm |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 30 mA |
| Housing length | 54.5 mm |
| Housing material | Plastic (ABS) |
| Protection class | III, operation on protective low voltage |
| Modulation | Clocked |
| Ambient light immunity | 3 kLx Clocked light, 10 kLx Sunlight |
| Sensitivity adjustment | Potentiometer |
| Switching frequency | 333 Hz |
| Ambient temperature during operation | -25 … +55 °C |
| Protection type | IP 67 |
| Connection | Connector, M12, 4-pin |
| Range | 0 … 10000 mm |
| Response time | 1.5 ms |
| Release time | 1.5 ms |
| Material | PMMA (Window) |
| Thread | M18 x 1 |
| Consisting of | Transmitter and Receiver |
