di-soric OBS 60 M 30 G3-T3: 207826 - Optical Movement Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | OBS 60 M 30 G3-T3 |
di-soric Optical Movement Sensors OBS 60 M 30 G3-T3, 207826 Technical Specifications:
| Specification | Value |
|---|
| Operating principle | Optical |
| Evaluation | digital |
| Design | Cuboid design |
| Switching output | Push-pull, 150 mA, NO/NC, switchable |
| Voltage drop (max.) | 2.5 V |
| Light source | Laser |
| Color | Infrared |
| Wavelength | 850 nm (Pp < 0,77 mW t = cw-Laser) |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 30 mA |
| Insulation voltage endurance | 500 V |
| Housing material | Aluminum (Black, Anodized) |
| Protection class | III, operation on protective low voltage |
| Ambient light immunity | 5 kLx |
| Switching hysteresis (max.) | Fixed 16 % max. 0.1 m/s |
| Sensitivity adjustment | Potentiometer |
| Ambient temperature during operation | #ERROR! |
| Protection type | IP 67 |
| Connection | Connector, M8, 3-pin |
| Connection cable | TK … |
| Display | LED Green - Operation, yellow - Switching output |
| Response time | 10 ms |
| Switching distance | 20 … 40 mm |
| Material | PMMA (Window) |
| Characteristics | For contactless feed control, also suitable at low speed and with wires |
