Di-soric MZET 9-25 PSL Magnetic Field Sensor
The Di-soric MZET 9-25 PSL Proximity Sensor offers Excentric mounting, pnp, 100 mA, NO, short-circuit-proof output, andCable, 2.0 m, 3-pin connection. Manufactured by Di-soric under the Di-soric Proximity Sensor category, this model belongs to the IS Series.
| Brand | Di-soric |
| Product Type | Magnetic Field Sensor |
| Model Number | MZET 9-25 PSL |
Di-soric MZET 9-25 PSL Magnetic Field Sensor - Technical Specifications
| Specification | Value |
|---|---|
| Current-carrying capacity | 100 mA, short-circuit-proof, polarity-safe |
| Service voltage | 10 … 30 V DC |
| No-load current (max.) | 10 mA |
| Insulation voltage endurance | 500 V |
| Cylinder groove | T-groove, Can be inserted into the groove from above |
| Mounting | Excentric |
| Housing material | Plastic (PA) |
| Material of cable | Polyurethane |
| Protection class | III, operation on protective low voltage |
| Switching output | pnp, 100 mA, NO, short-circuit-proof |
| Voltage drop (max.) | 2.5 V |
| Reproducibility | 0.2 mm |
| Display | LED yellow - Output signal |
| Switching frequency | 10000 Hz |
| Ambient temperature during operation | -25 … +80 °C |
| Protection type | IP 67 |
| Connection | Cable, 2.0 m, 3-pin |
| Material | Stainless steel (Fastening excentric) |
