di-soric LVX-O16: 206563 - Switching Light Curtains
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | LVX-O16 |
di-soric Switching Light Curtains LVX-O16, 206563 Technical Specifications:
| Specification | Value |
|---|
| Switching output | 19x |
| Service voltage | 20 … 26 V DC |
| Housing material | Plastic |
| Protection class | III, operation on protective low voltage |
| Ambient temperature during operation | 0 … +40 °C |
| Protection type | IP 00 |
| Connection | Connection compartment |
| Display | LED (Error indicator) |
| EMC directives | EN 61000-6-3:2001 / EN 61000-6-1:2001 |
| Assembly | DIN-rail mountable |
| Output function | configurable |
| Beam evaluation | Parameters can be configured horizontally / diagonally |
| Number of beams | 500 (Max. evaluable) |
| Cycle time per light beam | 0.05 ms (abhängig von Konfiguration und Reichweite der Lichtgitterleisten) |
| Inputs for which parameters can be set | 24 V DC, 12 mA, 3,000 Hz (1x) |
