di-soric LVHT52-500G3-RB4: 213674 - Optical Distance Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | LVHT52-500G3-RB4 |
di-soric Optical Distance Sensors LVHT52-500G3-RB4, 213674 Technical Specifications:
| Specification | Value |
|---|
| Design | Cuboid design |
| Switching output | Push-pull (1x), 100 mA, NO/NC |
| Voltage drop (max.) | 2 V |
| Light source | Laser |
| Color | Red |
| Wavelength | 650 nm (Pp < 0.65 mW t = 4 µs) |
| Service voltage | 18 … 30 V DC |
| No-load current (max.) | 60 mA |
| Insulation voltage endurance | 500 V |
| Housing dimensions | 51 x 51 x 17 mm |
| Housing material | Die-cast zinc (Black, powder-coated) |
| Protection class | III, operation on protective low voltage |
| Approvals | UL |
| Resolution | 0.3 … 0.50 mm (0.3 mm at 50 ... 300 mm, mode: standard, mean value 16, 0.5 mm at 300 ... 500 mm, mode: standard, mean value 16) |
| Reproducibility | 0.5 mm at 50 ... 300 mm, mode: standard, mean value 16, 1.0 mm at 300 ... 500 mm, mode: standard, mean value 16 |
| Sensitivity adjustment | Keypad |
| Switching frequency | 100 Hz (Max. 600 Hz in Speed sensor mode without filter) |
| Ambient temperature during operation | 0 … +50 °C |
| Protection type | IP 67 |
| Connection | Connector, M12, 4-pin |
| Connection cable | VK … /5 |
| Display | LED Green - Status, yellow - Switching output, Red - Signal weak |
| Characteristics | Radial plug connection |
| Measuring range | 50 … 500 mm |
| Weight | 102 g |
