Home Products Inductive Sensor di-soric IRDB 6 NSOK-IBS Di-soric IRDB 6 NSOK-IBS Proximity Sensor The Di-soric IRDB 6 NSOK-IBS Proximity Sensor offers npn, 200 mA, NO/NC, switchable output, andConnector, M12, 4-pin, A-coded connection. Manufactured by Di-soric under the Di-soric Proximity Sensor category, this model belongs to the IRDB Series.
Brand Di-soric Product Type Proximity Sensor Model Number IRDB 6 NSOK-IBS
Di-soric IRDB 6 NSOK-IBS Proximity Sensor - Technical Specifications Specification Value Product series IRDB Inductive Wire Break Sensors Operating principle inductive Service voltage 10 … 35 V DC (Supply Class 2) No-load current (max.) 11 mA Insulation voltage endurance 1000 V Housing material Plastic (PA) Protection class III, operation on protective low voltage Approvals UL Switching output npn, 200 mA, NO/NC, switchable Voltage drop (max.) 2 V Pulse stretching 10 … 150 ms adjustable Speed of parts (max.) 35 m/s Response time 0.50 ms Release time 10 ms Ambient temperature during operation -25 … +70 °C Protection type IP 67 Connection Connector, M12, 4-pin, A-coded Connection cable VK … Internal diameter 6.1 mm Material POM (Ring) Resolution Ø 0.2 mm (Copper wire) Sensitivity adjustment Potentiometer Assembly distance to metal (min.) 2 mm
