di-soric FSB 50 M G3-B8: 207787 - Color Sensors
| Brand | Di-soric |
| Product Type | Photoelectric Sensor |
| Model Number | FSB 50 M G3-B8 |
di-soric Color Sensors FSB 50 M G3-B8, 207787 Technical Specifications:
| Specification | Value |
|---|
| Switching output | pnp+npn (4x), < 100 mA |
| Voltage drop (max.) | 2 V |
| Light source | LED |
| Color | White |
| Service voltage | 18 … 28 V DC |
| No-load current (max.) | 500 mA |
| Housing dimensions | 50 x 50 x 21 mm |
| Housing length | 21 mm |
| Housing height | 50 mm |
| Housing width | 50 mm |
| Housing material | Aluminum (Anodized) |
| Protection class | III, operation on protective low voltage |
| Switching hysteresis (max.) | 10 % |
| Ambient temperature during operation | -10 … +55 °C |
| Protection type | IP 54 |
| Connection | Connector, M9, 8-pin |
| Range | Dependent on fiber-optic cable |
| Display | LED (Channel state (4x), programming (5x)) |
| Response time / scanning frequency | 10 ms / 100 Hz or 1 ms / 1,000 Hz, parametrierbar |
