Di-soric DCCKR 6.5 V 02 PSK-K-TSL Proximity Sensor

The Di-soric DCCKR 6.5 V 02 PSK-K-TSL Proximity Sensor offers Cylinder design, pnp, 200 mA, NO output, andPigtail, 0.3 m, M8, 3-pin, A-coded connection. Manufactured by Di-soric under the Di-soric Proximity Sensor category, this model belongs to the DCC Series.

di-soric DCCKR 6.5 V 02 PSK-K-TSL
Datasheet
BrandDi-soric
Product TypeProximity Sensor
Model NumberDCCKR 6.5 V 02 PSK-K-TSL

Di-soric DCCKR 6.5 V 02 PSK-K-TSL Proximity Sensor - Technical Specifications

SpecificationValue
Product seriesIND-100 Short design
Operating principleinductive
DesignCylinder
Installation typeFlush
Internal power consumption< 10 mA
Switching distance (SN)2 mm
Standardized measuring plate6.5 x 6.5 x 1 mm
Service voltage10 … 30 V DC
Insulation voltage endurance500 V
Housing length16 mm
Housing materialStainless steel
Protection classIII, operation on protective low voltage
Switching outputpnp, 200 mA, NO
Voltage drop (max.)2.4 V
Ambient temperature during operation-25 … +70 °C
Protection typeIP 67
ConnectionPigtail, 0.3 m, M8, 3-pin, A-coded
Material of cablePolyurethane
Characteristicsincreased operating distance
Switching hysteresis (max.)< 15 %
Switching frequency3000 Hz
DiameterØ 6.5 mm (Diameter)
