di-soric DCC 08 M 02 PSLK/2m PUR Inductive Proximity Sensor

Name: di-soric DCC 08 M 02 PSLK/2m PUR Inductive Proximity Sensor
Availability: InStock
Rating: 4.2 (5 reviews)

The di-soric DCC 08 M 02 PSLK/2m PUR Proximity Sensor offers Thread design, pnp, 200 mA, NO output, andCable, 2.0 m (flying leads) connection. Manufactured by di-soric under the di-soric Proximity Sensor category, this model belongs to the DCC Series.

Datasheet

Brand	Di-soric
Product Type	Proximity Sensor
Model Number	DCC 08 M 02 PSLK/2m PUR

di-soric DCC 08 M 02 PSLK/2m PUR Proximity Sensor - Technical Specifications

Specification	Value
Operating principle	inductive
Design	Thread
Thread	M8 x 1
Installation type	Flush
Internal power consumption	< 10 mA
Switching distance (SN)	2 mm
Standardized measuring plate	8 x 8 x 1 mm
Service voltage	10 … 30 V DC
Insulation voltage endurance	According to IEC 60947-5-2 (7.2.3.1)
Housing length	35 mm
Housing material	Stainless steel (V2A)
Protection class	III, operation on protective low voltage
Switching output	pnp, 200 mA, NO
Voltage drop (max.)	2 V
Ambient temperature during operation	-25 … +70 °C
Protection type	IP 67
Connection	Cable, 2.0 m (flying leads)
Material of cable	Polyurethane
Characteristics	increased operating distance
Switching hysteresis (max.)	< 10 %
Switching frequency	5000 Hz
LED Anzeige	Yes
