Home Products Inductive Sensor di-soric DCC 05 V 2.5 NSLK Di-soric DCC 05 V 2.5 NSLK Proximity Sensor The Di-soric DCC 05 V 2.5 NSLK Proximity Sensor offers Thread design, npn, 200 mA, NO output, andCable, 2.0 m (flying leads) connection. Manufactured by Di-soric under the Di-soric Proximity Sensor category, this model belongs to the DCC Series.
Brand Di-soric Product Type Proximity Sensor Model Number DCC 05 V 2.5 NSLK
Di-soric DCC 05 V 2.5 NSLK Proximity Sensor - Technical Specifications Specification Value Product series INM-300 Miniature Extended Operating principle inductive Design Thread Thread M5 x 0.5 Installation type Flush Internal power consumption < 10 mA Switching distance (SN) 2.5 mm Standardized measuring plate 7.5 x 7.5 x 1 mm Service voltage 10 … 30 V DC Insulation voltage endurance According to IEC 60947-5-2 (7.2.3.1) Housing length 25 mm Housing material Nickel-silver (chromium-plated) Protection class III, operation on protective low voltage Switching output npn, 200 mA, NO Voltage drop (max.) 2 V (200 mA) Ambient temperature during operation -25 … +70 °C Protection type IP 67 Connection Cable, 2.0 m (flying leads) Material of cable PVC Characteristics extremely high operating distance Switching hysteresis (max.) 3 … 15 % Switching frequency 800 Hz Tightening torque 1.5 Nm
