Home Products Inductive Sensor di-soric DCB 30 MN 20 PS-B3 Di-soric DCB 30 MN 20 PS-B3 Proximity Sensor The Di-soric DCB 30 MN 20 PS-B3 Proximity Sensor offers Thread design, pnp, 400 mA, NO output, andConnector, M12, 3-pin, A-coded connection. Manufactured by Di-soric under the Di-soric Proximity Sensor category, this model belongs to the DCC Series.
Brand Di-soric Product Type Proximity Sensor Model Number DCB 30 MN 20 PS-B3
Di-soric DCB 30 MN 20 PS-B3 Proximity Sensor - Technical Specifications Specification Value Product series INE Extended Operating principle inductive Design Thread Thread M30 x 1.5 Installation type non-flush Internal power consumption < 20 mA Switching distance (SN) 20 mm Standardized measuring plate 60 x 60 x 1 mm Service voltage 10 … 30 V DC Insulation voltage endurance 500 V Housing length 76 mm Housing material Brass (nickel-plated) Protection class III, operation on protective low voltage Switching output pnp, 400 mA, NO Voltage drop (max.) 1 V (400 mA) Ambient temperature during operation -25 … +70 °C Protection type IP 67 Connection Connector, M12, 3-pin, A-coded Connection cable VK … Characteristics increased operating distance Material PBT (Sensor probe) Switching hysteresis (max.) 1 … 20 % Switching frequency 200 Hz LED Anzeige Yes
