Delta VFD2A7ME43ANNAA Variable Frequency Drive
The Delta VFD2A7ME43ANNAA Variable Frequency Drive is designed for controlled motor operation, supporting 0.75 kW and 1 HP applications using a stable Three-phase AC, 380V~480V input at 50 / 60Hz. The drive uses a Natural Air Cooling thermal method and features an IP20 enclosure suitable for cabinet-integrated environments requiring internal protection. Manufactured by Delta, part of the Delta Variable Frequency Drive family within the Delta ME300 Series.
| Brand | Delta |
| Product Type | VFD |
| Model Number | VFD2A7ME43ANNAA |
Delta VFD2A7ME43ANNAA Variable Frequency Drive - Technical Specifications
| Specification | Value |
|---|---|
| Applicable Motor Output ( kW) | 0.75 kW |
| Applicable Motor Output (HP) | 1 HP |
| Input Voltage / Frequency | Three-phase AC, 380V~480V (-15% ~ + 10%), 50 / 60Hz |
| Heavy DutyRated Output Current | 2.7 A |
| Normal DutyRated Output Current | 3 A |
| Cooling Method | Natural Air Cooling |
| IP Level | IP20 |
| EMC Filter | None |
| Safe Torque Off (STO) | None |
| Model Type | Standard model |
| Braking Chopper | Built-in |
| Output Frequency | 0 to 599.00 Hz |
| MODBUS COM | Built-in |
| Control Methods | V/F, SVC |
| Size: W Γ H (mm) | 68 Γ 128 |
| Size: D (mm) | 127 |
| Net Weight | 0.9 kg |
IndMALL Automation offers the 3 Phase VFD Delta VFD2A7ME43ANNAA, a compact and efficient 1 HP 3-phase AC drive from the ME300 series. Designed for industrial applications, this drive supports an input voltage range of 380V~480V AC and is compatible with motors rated at 1 HP (0.75 kW).
Delivering a heavy-duty rated output current of 2.7 A and a normal-duty rated output current of 3 A, this VFD ensures reliable performance under varying load conditions. It features advanced control methods such as V/F and SVC, a built-in braking chopper, and supports an output frequency range of 0 to 599.00 Hz for precise motor control.
With IP20 protection and natural air cooling, the drive is robust and low-maintenance. Measuring 68 Γ 128 Γ 127 mm and weighing only 0.9 kg, it is lightweight and compact, ideal for space-constrained installations. Contact IndMALL Automation for competitive pricing and expert support for your Delta 3 phase VFD requirements.
