During technical comparisons, VFD17AMS43AFSHA appears alongside Schneider VFD, Delta Vfd004El21W 1 and Delta VFD so engineers assess signal types, ingress protection, and ambient tolerances accurately.
Delta VFD17AMS43AFSHA Variable Frequency Drive
The Delta VFD17AMS43AFSHA Variable Frequency Drive is designed for controlled motor operation, supporting 7.5 kW and 10 HP applications using a stable 460V, Three-phase AC 380 V ~480 V, 50 / 60 Hz input operation. It delivers a rated 17 A Heavy duty output current and 20.5 A Normal duty output current. The drive uses a Fan cooling method and features an IP20 enclosure suitable for cabinet-integrated environments requiring internal protection. Manufactured by Delta, part of the Delta Variable Frequency Drive family within the Delta MS300 Series.
| Brand | Delta |
| Product Type | VFD |
| Model Number | VFD17AMS43AFSHA |
Delta VFD17AMS43AFSHA Variable Frequency Drive - Technical Specifications
| Specification | Value |
|---|---|
| Input Voltage / Frequency | 460V, Three-phase AC 380 V ~480 V, 50 / 60 Hz |
| Applicable Motor Output ( kW) | 7.5 kW |
| Applicable Motor Output (HP) | 10 HP |
| Heavy Duty Rated Output Current (A) | 17 A |
| Normal Duty Rated Output Current (A) | 20.5 A |
| Cooling Method | Fan cooling |
| IP Level | IP20 |
| EMC Filter | Built-in EMC Filter |
| Safe Torque Off (STO) | Integrated STO |
| Model Type | High Speed Model |
| Braking Chopper | Built-in Braking Chopper |
| Output Frequency | 0.00 ~ 1500.0Hz (ΓΒ±0.1%) |
| Control Methods | V/F, SVC, FOC Sensorless |
| Size: W Γ H (mm) | 109Γ207 |
| Size: D (mm) | 187 |
