Delta VFD040EL43W-1 Variable Frequency Drive
The Delta VFD040EL43W-1 Variable Frequency Drive is designed for controlled motor operation, supporting 4 kW and 5.5 HP applications using a stable 460V, Three-Phase, AC 380 V ~ 480 V input at 50 / 60Hz. It delivers a rated 9 A output current with an 7.4 kVA output capacity, enabling dependable speed and torque adjustment across industrial equipment. The drive uses a Fan Cooling thermal method and features an IP20 enclosure suitable for cabinet-integrated environments requiring internal protection. Manufactured by Delta, part of the Delta Variable Frequency Drive family within the Delta EL-W.
| Brand | Delta |
| Product Type | VFD |
| Model Number | VFD040EL43W-1 |
Delta VFD040EL43W-1 Variable Frequency Drive - Technical Specifications
| Specification | Value |
|---|---|
| Applicable Motor Output ( kW) | 4 kW |
| Applicable Motor Output (HP) | 5.5 HP |
| Input Voltage / Frequency | 460V, Three-Phase, AC 380 V ~ 480 V, 50 / 60 Hz |
| Output Current (A) | 9 A |
| Output Capacity (kVA) | 7.4 kVA |
| Cooling Method | Fan Cooling |
| IP Level | IP20 |
| Pollution Degree | 2 |
| Storage/Transportation Temperature | 20βC~60βC |
| Ambient Humidity | Below 90% RH (non-condensing) |
| V/F Pattem | SPWM (Sinusoidal Pulse Width Modulation) control (V/F control) |
| Input Frequency Tolerance | Β±5 % (47 Hz ~ 63 Hz) |
| Voltage Tolerance | Β±10 % (342 V ~ 528 V) |
| DC Choke | N / A |
| Methods of Packing | -1: Individual Package |
| Net Weight | 1.4 kg |
