Delta PMU-13V155WCBA Panel Mount Power Supply
Delta PMU-13V155WCBA is a Panel Mount PMU Series power supply providing 13.8V DC output with 151W rated power, suitable for industrial control, communication, and embedded systems requiring reliable DC power. It delivers 9.5A and 1.5A outputs, supporting multiple modules and devices in automation setups. The unit operates with a selectable nominal input voltage of 100-120Vac or 200-240Vac and a frequency range of 50-60Hz for stable performance. Designed for versatility and durability, it operates from -20°C to +70°C with storage support from -40°C to +85°C. Manufactured by Delta industrial automation, this model belongs to the Delta power supply solutions family and is part of the Delta Panel Mount PMU Series, delivering dependable DC output for a wide range of industrial and commercial applications.
| Brand | Delta |
| Product Type | SMPS |
| Product | PMU-13V155WCBA |
Delta Panel Mount PMU Series PMU-13V155WCBA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 9.5A,1.5A |
| Output Voltage | 13.8V |
| Output Voltage Adjustment Range | 12-14Vdc |
| Output Power | 151W |
| Nominal Input Voltage | 100-120Vac, 200-240Vac (Selectable by Switch) |
| Input Voltage Range | 90-132Vac, 180-264Vac (Selectable by Switch) |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| Input Current | < 2.5A @ 115Vac, < 1.5A @ 230Vac |
| Efficiency at 100% load | > 85.0% @ 115Vac > 86.0% @ 230Vac |
| Inrush Current | (Cold Start) < 25A @ 115Vac & 230Vac |
| Leakage Current | < 0.5mA @ 264Vac |
| Case Chassis / Cover | AL / SGCC |
| Indicator | LED Indicator: Green LED: DC OK Red LED: Battery Connected in Reverse Polarity |
| Cooling System | Convection |
| Unit Weight | 0.60 kg (1.32 lb) |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) |
| Pollution Degree | 2 |
| Bump Test (Operating) | IEC 60068-2-29, 10G (100m/S²) for a duration of 11ms,1000 times per direction, 3000 times in total |
| Over Voltage Category | II |
The Delta PMU-13V155WCBA Panel Mount PMU Series is engineered for reliable operation in industrial control systems, communication networks, and embedded automation modules. Its dual-output design, providing 9.5A and 1.5A, ensures stable voltage distribution to multiple devices simultaneously. The power supply’s selectable input voltage and wide tolerance make it ideal for installations across different electrical environments, while the DIN-compatible panel mount design allows organized installation in control panels, reducing clutter and improving system safety.
Operational efficiency is enhanced with protection features that monitor input currents and prevent overloading. The unit’s Green LED indicator confirms DC output status at a glance, helping technicians verify operation without intrusive inspection. Its wide operating temperature range, from -20°C to +70°C, combined with a storage range of -40°C to +85°C, ensures uninterrupted performance even in harsh industrial environments. This makes the PMU Series highly suitable for critical applications where consistent, clean DC power is essential.
For engineers, system integrators, and industrial operators seeking dependable panel-mounted DC power, the Delta PMU-13V155WCBA offers 151W output at 13.8V with unmatched reliability. IndMALL provides this model with competitive pricing, easy quotation access, and dedicated customer support. Choosing this power supply ensures your industrial control systems, communication equipment, and embedded devices receive stable, continuous power for maximum efficiency, protection, and long-term operational stability, making it a preferred solution across automation and industrial environments.
