PMT-24V350W1AM - Delta 1.46A 35W Panel Mount Power Supply

Name: Delta PMT-24V350W1AM
Brand: Delta
SKU: PMT-24V350W1AM
Rating: 4.4 (4 reviews)

Technical Specifications of Delta PMT-24V350W1AM 1.46A 35W Panel Mount Power Supply

Brand	Delta
Product Type	SMPS
Product	PMT-24V350W1AM

Delta 1.46A 35W Panel Mount Power Supply PMT-24V350W1AM Technical Specifications:

Specification	Value
Output Current	14.6A
Output Voltage	24V
Output Voltage Adjustment Range	20.0-26.4Vdc
Output Power	350.4W
Indicator	Green LED (DC OK)
Nominal Input Voltage	100-120Vac, 200-240Vac (Selectable by Switch)
Input Voltage Range	90-132Vac, 180-264Vac (Selectable by Switch)
Nominal Input Frequency	50-60Hz
Input Frequency Range	47-63Hz
Input Current	< 7.00A @ 115Vac, < 4.00A @ 230Vac
Case Chassis / Cover	Aluminium
Cooling System	Forced Cooling
Unit Weight	0.82 kg (1.81 lb)
Operating Temperature	-10°C to +70°C
Storage Temperature	-25°C to +85°C

Give Us a Call for Delta 1.46A 35W Panel Mount Power Supply PMT-24V350W1AM at the lowest pricing. In-depth Technical Analysis of PMT-24V350W1AM feature 14.6A, Output Current and 24V, Output Voltage 350.4W Output Power, suitable for diverse applications. It operates on a nominal input voltage of 100-120Vac, 200-240Vac (Selectable by Switch) and supports a frequency range of 47-63Hz and Input Current < 7.00A @ 115Vac, < 4.00A @ 230Vac. Additionally, it can handle a Input Voltage Range of 90-132Vac, 180-264Vac (Selectable by Switch). Nominal Input Frequency 50-60Hz designed for harsh conditions, it operates reliably within an Operating Temperature of -10°C to +70°C and offers storage safety between -25°C to +85°C. Elevate Your Project with a Quote for your requirement of 1.46A 35W Panel Mount Power Supply. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
