Delta PMR-5V320WDCA - 300W 5V Panel Mount Power Supply
Technical Specifications of Delta PMR-5V320WDCA 300W 5V Panel Mount Power Supply
| Brand | Delta |
| Product Type | SMPS |
| Product | PMR-5V320WDCA |
Delta 300W 5V Panel Mount Power Supply PMR-5V320WDCA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 60A |
| Output Voltage | 5V |
| Output Voltage Adjustment Range | 4.50-5.50Vdc |
| Output Power | 300W |
| Start-up Time | 3000ms typ. @ 115Vac, 1500ms typ. @ 230Vac (100% load) |
| Hold-up Time | 8ms typ. @ 115Vac & 230Vac |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 88-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| Input Current | < 5.00A@115Vac, < 2.50A @ 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Unit Weight | 0.86 kg (1.90 lb) |
| Operating Temperature | -20Β°C to +70Β°C (Cold start at -40Β°C) |
| Storage Temperature | -40Β°C to +85Β°C |
| Power De-rating | > 40Β°C de-rate power by 1% / Β°C, > 50Β°C de-rate power by 1.5% / Β°C < 110Vac de-rate power by 1% / 1V |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
Mail Us for your needs in Delta 300W 5V Panel Mount Power Supply PMR-5V320WDCA with budget-friendly prices. The Main Technical Parameters of PMR-5V320WDCA include 60A Output Current and Output Voltage 5V, 300W Output Power at competitive prices. Key technical parameters include a nominal input voltage of 100-240Vac, with an input voltage range of 88-264Vac, operating at a nominal input frequency of 50-60Hz. The input current is < 5.00A@115Vac, < 2.50A @ 230Vac, ensuring efficient performance. The power supply operates smoothly within an operating temperature range of -20Β°C to +70Β°C (Cold start at -40Β°C), making it ideal for diverse environments. It also features a storage temperature range from -40Β°C to +85Β°C, ensuring durability. Customize Your Experience with a Quote for your requirement of 300W 5V Panel Mount Power Supply. Experience the difference with our competitive pricing and superior support over other Suppliers.
