Delta PMH-12V100WCMS 12V 4.5A Panel Mount PMH Series Power Supply
Delta PMH-12V100WCMS is a 12V 4.5A Panel Mount PMH Series Power Supply designed for industrial automation, control panels, and embedded electronics that require stable DC output. Supporting a nominal input voltage of 100–240Vac with a wide input range of 85–264Vac, it ensures consistent performance across diverse industrial environments. With a nominal input frequency of 50–60Hz and a 54W output capacity, it efficiently powers PLCs, relays, sensors, and control circuits. Manufactured by Delta Industrial Automation, this model belongs to the Delta Power Supply Solutions category and the Delta Panel Mount PMH Series, providing reliable 12V DC output for embedded systems and industrial applications.
| Brand | Delta |
| Product Type | SMPS |
| Product | PMH-12V100WCMS |
Delta 4.5A 54W Panel Mount Power Supply PMH-12V100WCMS Technical Specifications:
| Specification | Value |
|---|---|
| Ouput Current | 4.5A |
| Output Voltage | 12V |
| Output Voltage Adjustment Range | 11-12Vdc |
| Output Power | 54W |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | < 1.50A @ 115Vac, < 0.80A @ 230Vac |
| Efficiency at 100% load | > 83% @115Vac & 230Vac |
| Inrush Current | (Cold Start) < 30A @ 115Vac, < 60A @ 230Vac |
| Leakage Current | < 0.75mA @ 240Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Noise Sound Pressure Level (SPL) | < 25dBA (1 Meter from power supply) |
| Unit Weight | 0.31 kg (0.68 lb) |
| Operating Temperature | -30°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) |
| Pollution Degree | 3 |
| Over Voltage Category | II |
The Delta PMH-12V100WCMS 12V 4.5A Panel Mount PMH Series Power Supply delivers 54W of stable DC power for industrial automation, control panels, and embedded electronics. Its compact panel mount design allows structured and safe installation in control cabinets while providing protection in harsh environments. Operating efficiently with input currents of <1.50A @115Vac and <0.80A @230Vac, it ensures reliable, energy-efficient performance. With an operating temperature range of -30°C to +70°C and storage temperature from -40°C to +85°C, the unit is built to withstand challenging industrial conditions. The PMH Series maintains low ripple, excellent line and load regulation, and consistent output to reduce the risk of equipment downtime. Secure input/output terminals allow fast and reliable connections. IndMALL provides competitive pricing, instant quotes, and responsive support, offering superior value compared to other distributors. Its robust design, industrial-grade performance, and compact footprint make it ideal for powering PLCs, relays, sensors, and other embedded devices, ensuring continuous, safe, and reliable DC output for critical industrial applications.
