Delta DVP40EC00R3 24DI 16DO PLC Controller
The Delta DVP40EC00R3 Programmable Logic Controller (PLC) offering 24 digital inputs, 16 relay outputs, and 4k steps program capacity with a 100–240VAC power supply. Designed for fast control tasks, it delivers a 10 ms response time while maintaining low 15.6 VA power consumption and stable 24VDC (5 mA) input compatibility. Manufactured by Delta, this Delta programmable logic controller belongs to the Delta Programmable Logic Controller family within the Delta DVP-EC3 Series.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP40EC00R3 |
Delta DVP40EC00R3 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Output Method | Relay |
| Power Supply | 100 ~ 240VAC (-15% ~ 10%); 50/60Hz + -5% |
| Number of Inputs and Type | 24- Digital |
| Number of Outputs and Type | 16- Relay |
| Fuse Capacity | 2A/ 250VAC |
| Power Consumption | 15.6VA |
| Program Capacity | 4k Steps |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage /Operation humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 10ms |
| Vibration/shock resistance | International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/ IEC61131-2 & IEC 68-2-27 (TEST Ea) |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
The Delta DVP40EC00R3 PLC is a built-in 24DI/16DO PLC developed for dependable digital control in industrial automation systems. As a Delta programmable logic controller, it combines 24 digital inputs, 16 relay outputs, and a 4k steps program capacity to support consistent logic execution. Operating on a 100–240VAC power supply, this controller is suited for standard factory electrical environments.
In real-world applications, the Delta PLC 24 input 16 output configuration is widely used in packaging machines, conveyors, material handling systems, and general automation panels. The DVP40EC00R3 supports quick machine response through its 10 ms processing time and reliable relay switching, making it suitable for control tasks where timing accuracy and stable output behavior are required.
The Delta DVP40EC00R3 is engineered for continuous industrial operation with low energy demand and stable electrical characteristics. As a Delta programmable logic controller within the DVP-EC3 Series, it operates reliably between 0°C and 55°C and integrates easily into compact control panels. Engineers selecting a 24DI/16DO PLC value this model for its balanced performance, electrical compatibility, and long-term reliability in industrial automation systems.
