Delta DVP10SX11T Programmable Logic Controller
Delta DVP10SX11T Programmable Logic Controller (PLC) is a compact controller designed for precise control in industrial automation systems. It features 4 digital inputs, 2 analog inputs, 2 analog outputs, and transistor (NPN) outputs, supported by a stable 24VDC power supply. With 16k steps program capacity and fast 10ms response time, it ensures accurate switching and reliable performance in real-time applications. Its low power consumption and consistent input compatibility make it suitable for packaging systems, conveyors, and control panels. Manufactured by Delta automation, it belongs to the industrial PLC range and the DVP-S series controllers used in automation environments.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP10SX11T |
Delta DVP10SX11T Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Output Method | Transistor (NPN) |
| Power Supply | 24VDC (-15%~20%) |
| Number of Inputs and Type | 4 (2AI) |
| Number of Outputs and Type | 2 (2AO) |
| Fuse Capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 5W |
| Program Capacity | 16k Steps |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storage /Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage /Operation humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 10ms |
| Vibration/shock resistance | Standard: IEC1131-2, IEC 68-2-6 (TEST Fc) / IEC1131-2 & IEC 68-2-27 (TEST Ea) |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
The DVP10SX11T is designed for compact automation systems that require both analog and digital control within limited panel space. It supports 2 analog inputs, 2 analog outputs, and digital I/O, allowing stable signal processing and efficient machine control. Its DIN rail mounting design enables easy integration into control panels, making it suitable for machines where space and wiring structure are critical.
With a 24VDC power supply, 16k steps program capacity, and 10ms response time, the controller maintains consistent operation under continuous industrial usage. Its low power consumption and noise resistance support stable performance in environments with electrical disturbances. The unit is built to handle regular switching tasks while maintaining accuracy in analog-based applications.
The DVP10SX11T is commonly used in applications such as temperature control, process automation, and signal-based operations where precise control is required. Its balanced combination of analog and digital functionality makes it suitable for compact machinery and OEM systems. This clear alignment between model capability, I/O structure, and application ensures reliable performance in industrial automation setups.
