Delta DVP06AD-S Programmable Logic Controller
The Delta DVP06AD-S Programmable Logic Controller (PLC) is a reliable Analog I/O Module designed for precise signal acquisition in automation systems. It provides 6 channels of analog voltage input (-10V~+10V) or current input (-20mA~+20mA) with a stable 14-bit resolution to ensure accurate data conversion. The module supports a built-in RS-485 interface for seamless communication and easy integration into industrial control networks. Ideal for monitoring, measurement, and process-level applications, it delivers dependable performance across varied environments. Manufactured by Delta within the Delta Programmable Logic Controller family, this model belongs to the Delta DVP-S Series.
| Brand | Delta |
| Product Type | Programmable Logic Controller |
| Model Number | DVP06AD-S |
Delta DVP06AD-S Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Built-in | RS-485 interface |
| Power Supply Voltage | 24VDC (-15%~20%) |
| Resolution | 14-bit |
| Analog I/O Modules | 6 points of analog |
| Fuse capacity | ES: 2A/ 250VAC; SV: 2.5A/ 30VDC |
| Power Consumption | 2W |
| Voltage input/output | Input voltage (-10 V ~ +10 V) |
| Current input/output | Outputcurrent (-20 mA ~ +20 mA) |
| Spike Voltage Durability | 1500VAC (Primary-secondary); 1500VAC (Primary-PE); 500VAC (Secondary-PE) |
| Insulation Impedance | >5 MΩ (all I/O point-to-ground: 500VDC) |
| Noise Immunity | ESD: 8 kV Air Discharge EFT: Power Line, 2 kV Digital I/O: 1 kV Analog & Communication I/O: 1 kV RS: 26 MHz~1GHz, 10V/m |
| Earth | The diameter of grounding wire shall not be shorter than that of the power supply cable. (When many PLCs are in use at the same time, please make sure every PLC is properly grounded.) |
| Storagr Operation Temperature | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Storage Operation Humidity | Storage: -25ºC ~70ºC (temperature) Operation: 0ºC ~55ºC (temperature) |
| Response Time | 3ms |
| Input Signal Voltage | 24VDC ±10% (5 mA) |
Delta is a globally recognized leader in automation technology, providing advanced PLC modules that deliver precision, reliability, and efficiency. Known for engineering excellence, Delta products are trusted across industries for their durability and performance. The DVP06AD-S stands out as a versatile analog input module that combines compact design with high-accuracy measurement. Designed for modern control systems, the Delta DVP06AD-S integrates seamlessly into industrial setups, offering dependable performance even in challenging environments. Engineers seeking a proven analog input solution often choose the Delta PLC DVP06AD-S for its stability and robust build.
The DVP06AD-S is equipped with 6 points of analog input, supporting both voltage (-10V to +10V) and current (-20mA to +20mA) signals. It offers a 14-bit resolution for precise data acquisition and features a built-in RS-485 interface for reliable communication. Operating on a 24VDC (-15%~20%) power supply, the module consumes just 2W, ensuring energy-efficient performance. Protection features include spike voltage durability up to 1500VAC and insulation impedance above 5MΩ. The Delta DVP06AD-S also meets strict noise immunity standards with ESD protection up to 8 kV and EFT resistance on power, digital, analog, and communication I/O. With a fast 3ms response time and IP-rated durability, the Delta PLC DVP06AD-S is built for dependable integration into industrial control environments.
Engineers deploy the DVP06AD-S in diverse applications such as process monitoring, machine automation, energy management, and data logging systems. Its ability to handle both voltage and current inputs makes it adaptable for multiple control scenarios, from manufacturing plants to research facilities. Compact in size yet rich in capability, the module supports stable operation in varied environmental conditions. For automation setups requiring accurate and consistent measurement, the DVP06AD-S remains a trusted choice for Delta 6 Points of Analog Input.
