DTMN02-V - Delta 0/12 V Pulse Voltage Temperature Controller
Technical Specifications of DTMN02-V Delta 0/12 V Pulse Voltage Temperature Controller
| Brand | Delta |
| Product Type | Temperature Controller |
| Product | DTMN02-V |
Delta 0/12 V Pulse Voltage Temperature Controller DTMN02-V Technical Specifications:
| Specification | Value |
|---|---|
| Input Power Supply | DC 24 V |
| Operating Voltage Range | 90% ~ 110% rated voltage |
| Power Consumption (Max.) | 5 W |
| Sampling Rate | 0.1 sec. / all 8 sets of input |
| Control Methods | PID, programmable PID, ON / OFF, manual |
| Communication Protocol | RS-485 DIP Switch: supports the Modbus protocol with RTU / ASCII communication format Ethernet RJ45 Port: support Modbus TCP and Ethernet/IP, compliant with IEEE802.3, IEEE802.3u Mini USB Port: supports USB2.0 communication standard |
| Internal Connection | Features internal connection terminals for 24 V power supply and communication signal transmission |
| Vibration Resistance | 10 ~ 55 Hz, 10 m/sยฒ for 10 mins in X, Y, Z directions |
| Shock Resistance | Max. 300 m/sยฒ, 3 times in 3 axes and 6 directions |
| Operating Ambient Temperature | 0ยฐC ~ 50ยฐC |
| Storage Temperature | 20ยฐC ~ 65ยฐC |
| Operating Altitude | < 2,000 m |
| Operating Ambient Humidity | 35% ~ 85% RH (non-condensing) |
| Input/Output | 2 IN-4 OUT |
Send Your Inquiry for Delta DTC1000 Temp Controllers, DTC1000R/V/C/L with cost-effective solutions. Essential Technical Specs of DTC1000R/V/C/L cover Modbus protocol, ASCII/RTU format, PID , programmable PID, Manual, ON/OFF, Analog input: 0.15 sec. Thermocouple or platinum RTD: 0.4 sec.
, RS-485 digital communication, 2,400bps ~ 38,400bps. It also delivers Max. 24 W, Rated voltage: 90% ~ 110%, DC24V. Isolated switching power. Capture the Best Deal with a Quote for your requirement of Delta DTC1000 Temp Controllers. Our pricing and support are designed to exceed the standards of other Traders & Suppliers.
