Delta DRM-24V240W1PN 10A 24V Power Supply
Delta DRM-24V240W1PN is a 10A 240W DIN Rail Power Supply designed for industrial automation applications requiring reliable DC power. It delivers a regulated 24V DC output with 10A current, ensuring efficient performance for control panels, automation systems, and process equipment. The unit operates with a nominal input voltage of 100–240Vac and supports a broad input range of 85–276Vac with 50–60Hz nominal frequency and 47–63Hz operational frequency. Manufactured by Delta industrial automation products, it is part of the Delta power supply solutions category and belongs to the Delta Cliq M SMPS 10A 24V series used across industrial environments requiring dependable power conversion and distribution.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRM-24V240W1PN |
Delta10A 240W DIN Rail Power Supply DRM-24V240W1PN Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 10A |
| Output Voltage | 24V |
| Output Voltage Adjustment Range | 24-28Vdc |
| Output Power | 240W |
| Line Regulation | 10mV Max. (@ 85-276Vac input, 100% load) |
| Load Regulation | 100mV Max. (@ 85-276Vac input, 0-100% load) |
| PARD | 50mVpp Max. |
| Start-up Time | 800ms Max. @ 100Vac, 650ms Max. @ 120Vac, 340ms Max. @ 230Vac |
| Hold-up Time | 46ms Typ. @ 100Vac & 120Vac & 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 5% @ 0-100% load Slew rate 0.1A/µs (@ 5Hz, 50Hz & 1kHz, 50% Duty Cycle) |
| Start-up with Capacitive Loads | 10,000µF Max. |
| Rise Time | 100ms Max. @ 100Vac & 120Vac & 230Vac (0µF, 24V, 10A) 120ms Max. @ 100Vac & 120Vac & 230Vac (10,000µF, 24V, 10A) |
| Power Boost Duration | 5 seconds Typ. 7 seconds Max. |
| Power Boost Recovery Time | 14 seconds Typ. |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-276Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| Nominal DC Input Voltage | 110-300Vdc |
| DC Input Voltage Range | 88-375Vdc |
| Input Current | 10.0A Max. @ 100Vac & 120Vac & 230Vac |
| Efficiency at 100% load | 92.64% Typ. @ 100Vac, 93.44% Typ. @ 120Vac, 94.84% Typ. @ 230Vac |
| Inrush Current | 10.0A Max. @ 100Vac & 120Vac & 230Vac |
| Power Factor at 100% load | 0.99 Typ. @ 100Vac, 0.98 Typ. @ 120Vac, 0.95 Typ. @ 230Vac |
| Leakage Current | (Enclosure to Neutral) < 0.25mA / 0.54mA @ 110Vac, 50Hz, TN/TT system / IT system < 0.38mA / 0.79mA @ 132Vac, 50Hz, TN/TT system / IT system < 0.74mA / 1.29mA @ 264Vac, 50Hz, TN/TT system / IT system |
| Power Dissipation | 0% load: 2.30W Typ. @ 100Vac, 2.34W Typ. @ 120Vac, 2.43W Typ. @ 230Vac 4.40W Max. @ 100Vac, 4.90W Max. @ 120Vac, 6.10W Max. @ 230Vac 100% load: 19.12W Typ. @ 100Vac, 16.91W Typ. @ 120Vac, 13.10W Typ. @ 230Vac 23.50W Max. @ 100Vac, 20.10W Max. @ 120Vac, 17.50W Max. @ 230Vac |
| Case Chassis / Cover | Aluminium |
| Indicator | Green LED (DC OK) and Red LED (Overload) |
| Cooling System | Convection |
| Input Terminal | 3 Pins (Rated 600V/35A) |
| Output Terminal | 6 Pins (Rated 300V/28A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 18-8 Output: AWG: 16-12 |
| Unit Weight | 0.94 kg (2.07 lb) |
| Operating Temperature | -25°C to +70°C (Cold start -40°C) |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | Vertical Mounting: > 60°C de-rate power by 2.5% / °C Horizontal Mounting: > 50°C de-rate power by 2.5% / °C |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC60068-2-27, Half Sine Wave: 30G for a duration of 18ms; 3 times per direction, 6 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, Sine Wave: 10-500Hz; 3G peak; displacement of 0.35mm; 60 min per axis for all X, Y, Z directions |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) for ITE application 0 to 2,500 Meters (8,200 ft.) for Industrial application |
| Pollution Degree | 2 |
| Bump Test (Operating) | IEC 60068-2-29, Half Sine Wave: 10G for a duration of 11ms, 1,000 times per direction, 6,000 times in total |
| Over Voltage Category | III According to IEC/EN 62477-1 / EN 60204-1 (clearance and creepage distances) and IEC 62103 (safety part) |
| Signal Terminal | - |
The Delta DRM-24V240W1PN is commonly installed in industrial control cabinets, automation lines, and machinery requiring a stable 24V DC supply with high current capability. Its DIN rail mounting allows organized and secure integration within panels while providing protection against accidental contact or environmental hazards. The unit’s green DC OK LED and red overload indicator enable quick operational status checks, ensuring smooth industrial operation and minimizing downtime.
Engineered for demanding industrial environments, the power supply handles continuous operation with a maximum input current of 10.0A across input voltages of 100V, 120V, and 230V. It features wide operating temperature support from -25°C to +70°C, with cold start down to -40°C, and storage temperatures between -40°C and +85°C. This durability allows reliable performance even under extreme conditions, maintaining consistent voltage and current output to sensitive automation equipment.
For businesses and industrial setups seeking a robust 10A 240W DIN Rail Power Supply, the Delta DRM-24V240W1PN provides dependable DC power conversion, stable operation under varying loads, and long-term reliability. Its compact design, efficient performance, and high-quality construction make it an ideal choice for factories, process control systems, and automation applications. With competitive pricing and dedicated support, IndMALL ensures a trusted supply solution for all industrial power requirements.
