Delta DRL-24V480W1AA 24V 20A DIN Rail Power Supply
The Delta DRL-24V480W1AA is a robust 20A 24V DIN Rail Power Supply providing 480W output for industrial control panels, machine automation, and process equipment. It supports a nominal input voltage of 100-240Vac with an input range of 85-264Vac at 50-60Hz. Manufactured by Delta industrial automation products, this power supply is part of Delta power supply solutions and the LYTE Series DIN Rail Power Supplies, ensuring stable DC power for demanding industrial applications.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRL-24V480W1AA |
Delta 20A 24V DIN Rail Power Supply DRL-24V480W1AA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 20A |
| Output Voltage | 24V |
| Output Power | 480W |
| Output Voltage Adjustment Range | 22-28Vdc |
| Line Regulation | < 0.5% (@ 85-264Vac, 100% load) |
| Load Regulation | < 1.5% (0-100% load)@ > -10°C to +70°C < 2.0% ( 0-100% load) @ ≤ -10°C to -20°C |
| PARD | < 120mVpp @ > -10°C to +70°C < 240mVpp @ ≤ -10°C to -20°C |
| Start-up Time | 1000ms typ.@ 115Vac & 230Vac (100% load) |
| Hold-up Time | 10ms typ.@ 115Vac (100% load) 16ms typ.@ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 10% (2400mVpp) @ 85-264Vac input, 0-50% load, 50-100% load (Slew Rate: 0.1A/μs) |
| Start-up with Capacitive Loads | 8,000µF Max |
| Rise Time | 100ms typ. @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | 5.4A typ.@115Vac, 2.7A typ.@ 230Vac |
| Efficiency at 100% load | 85% typ. @ 115Vac, 88% typ. @ 230Vac |
| Inrush Current | 40A typ.@115Vac, 80A typ.@ 230Vac |
| Leakage Current | < 1mA @ 264Vac |
| Case Chassis / Cover | SGCC / Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Unit Weight | 1.30 kg (2.87 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10Hz to 500Hz @ 19.6m/s² (2G peak); displacement of 0.35mm; 10 min per cycle, 60 min for all X, Y, Z direction |
| Shock Test (Operating) | IEC 60068-2-27, 27, Half Sine Wave: 4G for duration of 22ms; 3 time per direction, 9 times in total |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | > 40°C de-rate power by 1.67% / °C @ 115Vac (90-229Vac) > 50°C de-rate power by 2.5% / °C @ 230Vac (230-264Vac) < 100Vac de-rate power by 1% / Vac |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 27, Half Sine Wave: 50G for duration of 22ms; 3 times per direction, 9 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, Random: 5Hz to 500Hz; 2.09Grms; 20 min per axis for all X, Y, Z directions |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) |
| Pollution Degree | 2 |
| Power Dissipation | 0% load: 5W @ 115Vac 4W @ 230Vac 100% load: 50W @ 115Vac 40W @ 230Vac |
| Input Terminal | 3 Pins (Rated 600V/35A) |
| Output Terminal | 6 Pins (Rated 300V/28A) |
| Signal Terminal | 6 Pins (Rated 300V/28A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 16-12 Output: AWG 16-14 (2 pieces of wire), AWG 12 Signal: AWG 16-12 |
The Delta DRL-24V480W1AA is widely used in industrial control systems, factory automation, and equipment requiring reliable 24V DC power. Its DIN rail mounting design supports organized and secure installation, while the Green LED DC OK indicator provides real-time operational monitoring. Input and output terminals are engineered for safe, stable connections to handle heavy-duty current loads.
Designed to operate under extreme industrial conditions, this 20A 24V DIN Rail Power Supply ensures continuous DC output across an operating temperature range of -20°C to +70°C, with storage tolerance from -40°C to +85°C. The device maintains stable output voltage even under fluctuating input conditions, protecting critical industrial components and guaranteeing uninterrupted system performance in high-demand environments.
For industries requiring high-capacity and dependable DC power, the Delta DRL-24V480W1AA offers consistent 480W output, reliable performance, and long-term durability. Secure a quote today to access competitive pricing and dedicated support, making it an ideal choice for industrial automation, process equipment, and control panel applications.
