Delta DRL-24V120W1AA 5A 24V DIN Rail Power Supply
The Delta DRL-24V120W1AA is a high-performance 5A 24V DIN Rail Power Supply designed for industrial automation, process equipment, and machine control systems requiring stable DC output. It delivers 120W of reliable power and operates over a wide input voltage range of 85-264Vac with 50-60Hz frequency compatibility. Manufactured by Delta industrial automation products, it is part of Delta power supply solutions and the LYTE Series DIN Rail Power Supplies, providing efficient and continuous performance in demanding industrial environments.
| Brand | Delta |
| Product Type | SMPS |
| Product | DRL-24V120W1AA |
Delta 5A 24V DIN Rail Power Supply DRL-24V120W1AA Technical Specifications:
| Specification | Value |
|---|---|
| Output Current | 5A |
| Output Voltage | 24V |
| Output Power | 120W |
| Output Voltage Adjustment Range | 22-28Vdc |
| Line Regulation | < 0.5% (@ 85-264Vac, 100% load) |
| Load Regulation | < 1% (0-100% load) |
| PARD | < 120mVpp @ > -10°C to +70°C < 240mVpp @ ≤ -10°C to -20°C |
| Start-up Time | 200ms typ. @ 115Vac & 230Vac (100% load) |
| Hold-up Time | 20ms typ. @ 115Vac (100% load) 90ms typ. @ 230Vac (100% load) |
| Dynamic Response (Overshoot & Undershoot O/P Voltage) | ± 10% @ 85-264Vac input, 0-100% load (Slew Rate: 0.1A/μs) |
| Start-up with Capacitive Loads | 8,000µF Max |
| Rise Time | 30ms typ. @ nominal input (100% load) |
| Nominal Input Voltage | 100-240Vac |
| Input Voltage Range | 85-264Vac |
| Nominal Input Frequency | 50-60Hz |
| Input Frequency Range | 47-63Hz |
| DC Input Voltage Range | 120-375Vdc |
| Input Current | 2.2A typ. @ 115Vac, 1.2A typ. @ 230Vac |
| Efficiency at 100% load | 85% typ. @ 115Vac, 88% typ. @ 230Vac |
| Inrush Current | 20A typ. @ 115Vac, 40A typ. @ 230Vac |
| Leakage Current | < 0.25mA @ 264Vac |
| Case Chassis / Cover | SGCC / Aluminium |
| Indicator | Green LED (DC OK) |
| Cooling System | Convection |
| Unit Weight | 0.54 kg (1.19 lb) |
| Vibration (Operating) | IEC 60068-2-6, Sine Wave: 10Hz to 500Hz @ 19.6m/s² (2G peak); displacement of 0.35mm; 10 min per cycle, 60 min for X direction |
| Shock Test (Operating) | IEC 60068-2-27, 27, Half Sine Wave: 10G for duration of 11ms; 1 time in X axis |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power De-rating | -10°C to -20°C de-rate power by 2%/°C > 40°C de-rate power by 1.67% / °C @ 115Vac > 50°C de-rate power by 2.5% / °C @ 230Vac < 100Vac de-rate power by 1% / Vac |
| Operating Humidity | 5 to 95% RH (Non-Condensing) |
| Shock Test (Non-Operating) | IEC 60068-2-27, 27, Half Sine Wave: 50G for duration of 11ms; 3 times per direction, 9 times in total |
| Vibration (Non-Operating) | IEC 60068-2-6, Random: 5Hz to 500Hz; 2.09Grms; 20 min per axis for all X, Y, Z directions |
| Operating Altitude | 0 to 5,000 Meters (16,400 ft.) |
| Pollution Degree | 2 |
| Power Dissipation | 0% load: 0.65W @ 115Vac & 230Vac 100% load: 13.3W @ 115Vac & 230Vac |
| Input Terminal | 3 Pins (Rated 600V/35A) |
| Output Terminal | 6 Pins (Rated 300V/28A) |
| Signal Terminal | 6 Pins (Rated 300V/28A) |
| Noise Sound Pressure Level (SPL) | < 25dBA |
| Mounting Rail | Standard TS35 DIN Rail in accordance with EN 60715 |
| Wire | Input: AWG 18-8 Output: AWG 20-12 Signal: AWG 24-12 |
The Delta DRL-24V120W1AA is widely used in industrial control panels, automation systems, and machine operation setups that require precise 24V DC power. Its compact DIN rail design ensures organized panel installation, while the green LED DC OK indicator enables operators to quickly verify system status. Secure input and output terminals provide reliable connections, supporting consistent power delivery for critical industrial applications.
Engineered for harsh industrial environments, the power supply reliably operates from -20°C to +70°C, with a storage temperature range of -40°C to +85°C. Its design ensures stable voltage and current output even under fluctuating input conditions, maintaining operational continuity in industrial automation, process equipment, and machine control systems. Its robust construction ensures safety, durability, and long-term reliability in compact spaces.
For industries seeking a dependable 5A 24V DIN Rail Power Supply, the Delta DRL-24V120W1AA provides high-quality DC power conversion, consistent industrial operation, and operational efficiency. Request a quote today to access competitive pricing and dedicated support, ensuring dependable performance and reliability for all your automation and control panel requirements.
