Delta DRF-48V120W1GTA: 2.5A 120W DIN Rail Power Supply

Technical Specifications of Delta 2.5A 120W DIN Rail Power Supply DRF-48V120W1GTA:

Output Current	2.5A
Output Voltage	48V
Output Power	120W
Input Current	1.2 A typ. @ 115 Vac, 0.6 A typ. @ 230 Vac

Delta 2.5A 120W DIN Rail Power Supply DRF-48V120W1GTA Technical Specifications:

Specification	Value
Output Current	2.5A
Output Voltage	48V
Output Voltage Adjustment Range	48-55 Vdc
Output Power	120W
Line Regulation	± 0.5% @ 115 Vac & 230 Vac
Load Regulation	± 0.5%
PARD	< 100 mVpp @ 0°C to +70°C < 300 mVpp @ -30°C to 0°C
Start-up Time	300 ms typ. @ 115 Vac & 230 Vac
Hold-up Time	35 ms typ. @ 115 Vac & 230 Vac (100% load)
Dynamic Response (Overshoot & Undershoot O/P Voltage)	± 10% @ 115 Vac & 230 Vac input, 10-100% load (Slew Rate: 2.5 A/μS, 50% duty cycle @ 5 Hz & 10 kHz)
Start-up with Capacitive Loads	5,000 µF Max
Rise Time	30 ms typ. @ 115 Vac & 230 Vac
Nominal Input Voltage	100-240 Vac
Input Voltage Range	90-264 Vac
Nominal Input Frequency	50-60 Hz
Input Frequency Range	47-63Hz
DC Input Voltage Range	127-375 Vdc
Input Current	1.2 A typ. @ 115 Vac, 0.6 A typ. @ 230 Vac
Input Power (Standby Mode)	0.75W max @ 115 Vac & 230 Vac
Efficiency at 100% load	93.0% typ. @ 230 Vac
Inrush Current	40 A typ. @ 230 Vac
Power Factor at 100% load	> 0.95 @ 115 Vac & > 0.92 @ 230 Vac
Leakage Current	< 0.5 mA @ 240 Vac
Case Chassis / Cover	Metal
Indicator	Green LED DC OK
Cooling System	Convection
Input Terminal	3 Pins (Rated 600 V / 30 A)
Output Terminal	3 Pins (Rated 600 V / 30 A)
Signal Terminal	2 Pins (Rated 300 V / 6 A)
Noise Sound Pressure Level (SPL)	< 25 dBA
Mounting Rail	Standard TS35 DIN Rail in accordance with EN 60715
Wire	Input: AWG 18-12 Output: AWG 18-12 DC OK: AWG 22-16
Unit Weight	0.5 kg (1.10 lb)
Vibration (Operating)	IEC 60068-2-6, Sine Wave: 10Hz to 500Hz; 4G peak; 60 min per axis for all X, Y, Z directions
Operating Temperature	-30°C to +70°C (-40°C Cold Start)
Storage Temperature	-40°C to +85°C
Power De-rating	Temperature: > 60°C de-rate power by 2.5 % / °C Input Voltage: < 100Vac de-rate power by 1% / Vac
Operating Humidity	5 to 90% RH (Non-Condensing)
Shock Test (Non-Operating)	IEC 60068-2-27, Half Sine Wave: 50 G for duration of 11 ms; 3 times per direction
Operating Altitude	0 to 5,000 Meters (16,400 ft.)
Pollution Degree	2
Over Voltage Category	II (Compliance to EN 62477-1 OVC III with 2000 meters altitude)

Mail Us for your needs in Delta 2.5A 120W DIN Rail Power Supply DRF-48V120W1GTA with budget-friendly prices. The Main Technical Parameters of DRF-48V120W1GTA include 2.5A Output Current, 48V Output Voltage, 120W Output Power at competitive prices. It operates with a nominal input voltage of 100-240 Vac and supports an input voltage range of 90-264 Vac. The power supply covers a nominal input frequency of 50-60 Hz, with a broader input frequency range of 47-63Hz. For DC input, it accepts a range from 127-375 Vdc. With an input current of 1.2 A typ. @ 115 Vac, 0.6 A typ. @ 230 Vac, it ensures efficient performance. The unit features a Green LED DC OK indicator, aiding in quick status checks. Both input and output terminals have 3 Pins (Rated 600 V / 30 A) for secure connections. Designed for extreme environments, it operates from -30°C to +70°C (-40°C Cold Start) and has a storage temperature range of -40°C to +85°C. Customize Your Experience with a Quote for your requirement of 2.5A 120W DIN Rail Power Supply. Experience the difference with our competitive pricing and superior support over other Suppliers.
